0.9 USD/PC
Maximum Power(Pm): 1.5W
Operating Voltage(Vmp): 5V
Operating Current(Imp): 300mA
Dimension: 120x90x2.5mm
Encapsulation methods: ETFE Lamination
HIGHLIGHTS:
Impact resistance
Economical
High Strength with FiberGlass material FR-4
High electrical insulation
Attractive customizeable appearance
| Material: | Monocrystalline sillicon, FR-4 PCB, ETFE lamination, 120x90mm | |
| Peak power: | 1.5W | |
| Max voltage: | 5.0V | |
| Max current: | 300mA | |
| Open voltage: | 6.0V | |
| Short current: | 320mA | |
| Weight: | 26G | |
| Operating temperature | -40°C to +85°C | |
| Maximum system voltage | 1000VDC | |
| NOCT | 48°C+/-2°C | |
| Current temperature coefficient | %/K | 0.06+/-0.01 |
| Voltage temperature coefficient | mV/K | -(78+/-10) |
| Power temperature coefficient | %/K | -(0.5+/-0.05) |
Solar Panel Application：
ETFE solar panel for bike, electric cycle, backpack
ETFE solar panel for charger, toy, flashlight, educational kits
ETFE solar panel for crafts, toys, fountain, traffic signs
ETFE solar panel for school project, DIY projects
ETFE solar panel for agricultural canopy, irrigation system
ETFE solar panel for road sign lights,navigation lights,garden lights
ETFE solar panel for outdoor monitoring systems, security systems
Other applications.
